Dahua 6MP Smart Dual Light Eyeball Camera with 2.8mm Fixed Lens.
Dahua 6MP Smart Dual Light Eyeball Camera with 2.8mm Fixed Lens. Features H.265/H.264 compression with built-in IR and warm white illuminators (both u...
Dahua 6MP Smart Dual Light Eyeball Camera with 2.8mm Fixed Lens. Features H.265/H.264 compression with built-in IR and warm white illuminators (both up to 30m), SMD Plus, and perimeter protection with human/vehicle classification via tripwire and intrusion detection. Supports PoE or 12VDC power, IP67 weatherproofing, and up to 256GB MicroSD local storage.
Contact 0345 863 9750 for availability
SKU:
DH-IPC-HDW2649TMP-S-IL-0280B-Black
Click to copy
✔ Copied!
Product Details
Dahua 6MP Smart Dual Light Eyeball Camera with 2.8mm Fixed Lens. Features H.265/H.264 compression with built-in IR and warm white illuminators (both up to 30m), SMD Plus, and perimeter protection with human/vehicle classification via tripwire and intrusion detection. Supports PoE or 12VDC power, IP67 weatherproofing, and up to 256GB MicroSD local storage.
| Manufacturer | Dahua |
|---|---|
| Angle Adjustment | Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
| Certifications | CE-LVD (EN62368-1), CE-EMC (2014/30/EU) |
| Close Focus Distance | 1.0m |
| Day Night | Auto (ICR) / Colour / B/W |
| Field Of View | H: 112°, V: 61°, D: 132° |
| Housing Colour | Black |
| Illumination Type | Smart Dual Light (1x IR LED + 1x Warm Light) |
| Image Rotation | 0°/90°/180°/270° |
| Image Sensor | 1/2.7" CMOS |
| Interoperability | ONVIF Profile S, Profile G, Profile T; CGI |
| Lens Mount | M12 |
| Lens Type | Fixed-focal |
| Max Aperture | F1.6 |
| Max Frame Rate | 6MP @ 20fps; 4MP (2688×1520) @ 25/30fps |
| Max Resolution | 3288 × 1850 |
| Min Illumination Bw | 0.0007 lux @ F1.6 (30 IRE) |
| Min Illumination Colour | 0.007 lux @ F1.6 (30 IRE) |
| Min Illumination Illuminator On | 0 lux |
| Network Port | RJ-45 (10/100 Base-T) |
| Noise Reduction | 3D NR |
| Power Consumption Basic | 2.5W (12VDC), 3.4W (PoE) |
| Power Consumption Max | 4.6W (12VDC), 5.7W (PoE) |
| Power Supply | 12VDC / PoE |
| Privacy Masking | 4 areas |
| Smart Codec | Smart H.265+, Smart H.264+ |
| Smart Features | Perimeter Protection (Tripwire, Intrusion with human/vehicle classification), SMD Plus, Smart Dual Light, ROI, BLC, HLC |
| Storage | Micro SD card up to 256GB, FTP, SFTP, NAS |
| Video Compression | H.265, H.264, H.264H, H.264B, MJPEG (sub stream only) |
| Warm Light Distance | Up to 30m |
| WDR | 120dB |
| Camera Body Style | Eyeball |
| Casing Material | Inner core: Metal; Cover: Metal; Decoration ring: Plastic; Mounting plate: Metal |
| Dimensions | 99.1mm × Ø121.9mm |
| Net Weight | 0.53kg |
| Operating Temperature | -40°C to +60°C |
| Operating Humidity | ≤95% RH, non-condensing |
| Built-in Audio | Built-in microphone; G.711a, G.711Mu, PCM, G.726 |
| Lens Size | 2.8mm |
| Ingress Protection | IP67 |
| IR Length | Up to 30m |
| Resolution | 6MP |
