Dahua Hi-Fidelity Omni-Directional Audio Pickup with Ambient Noise Cancellation.
Dahua Hi-Fidelity Omni-Directional Audio Pickup with Ambient Noise Cancellation. Metal construction with IP66-rated waterproof and dustproof housing. ...
Dahua Hi-Fidelity Omni-Directional Audio Pickup with Ambient Noise Cancellation. Metal construction with IP66-rated waterproof and dustproof housing. Covers a pickup area of 5–100 m² with a frequency response of 20Hz–20kHz and a signal-to-noise ratio of 68dB.
Contact 0345 863 9750 for availability
SKU:
DH-HAP320-V
Click to copy
✔ Copied!
Color
Silver
Click to copy
✔ Copied!
Product Details
Dahua Hi-Fidelity Omni-Directional Audio Pickup with Ambient Noise Cancellation. Metal construction with IP66-rated waterproof and dustproof housing. Covers a pickup area of 5–100 m² with a frequency response of 20Hz–20kHz and a signal-to-noise ratio of 68dB.
| Manufacturer | Dahua |
|---|---|
| Certifications | CE, FCC |
| Connector | RCA female connector, DC power connector |
| Directional Characteristic | Omni-directional |
| Dynamic Range | 84dB |
| Frequency Response | 20Hz–20kHz |
| Material | Metal |
| Max Sound Pressure | 110dBSPL (1kHz, THD 1%) |
| Microphone Type | High-fidelity waterproof omni-directional microphone |
| Noise Cancellation | Ambient Noise Cancellation (ANC) |
| Output Impedance | 100Ω (non-equilibrium) |
| Output Signal Amplitude | 2.5Vpp / 90dBSPL |
| Pickup Scope | 5–100 m² |
| Sensitivity | -24 ± 3dB |
| SNR | 68dB (re 94dBSPL = 1Pa @ 1kHz) |
| Working Current | 60mA |
| Working Temperature | -30°C to +70°C |
| Working Voltage | DC 12V |
| Dimensions | Ø80mm × 23.5mm |
| Ingress Protection | IP66 |
