Dahua 16 Channels Penta-brid 4K-N/5MP WizSense DVR
H.265+/H.265 dual-stream video compression.
Supports Full-channel AI-Coding.
Supports HDCVI/AHD/TVI/CVBS/IP video inputs.
Max 32 channels IP came...
- H.265+/H.265 dual-stream video compression.
- Supports Full-channel AI-Coding.
- Supports HDCVI/AHD/TVI/CVBS/IP video inputs.
- Max 32 channels IP camera inputs, each channel up to 8MP; Max 128 Mbps incoming bandwidth.
- Up to 8 channels video stream (analogue channel) Perimeter Protection.
- Up to 16 channels video stream (analogue channel) SMD Plus.
- Up to 2 channels video stream (analogue channel) human face recognition.
- IoT & POS functionalities.
In Stock
SKU
DH-XVR5216AN-4KL-I3-16P
Product Details
Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-4KL-I3 Series featuring max. full-channel SMD Plus to benefit customers from AI upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.
| Manufacturer | Dahua |
|---|---|
| Camera Type | Analogue |
| Colour | Black |
| Channels | 16CH |
| HDD/SATA Ports | 2 |
| Resolution | 4KL |
| Case Size | 1U |
| Video Output | 1 HDMI, 1 VGA VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Encode | Main stream: All channels 4K@(1-7fps); 6MP@(1-10fps); 5MP@(1-12fps); 4K-N/4MP/3MP@(1-15fps); 4M-N/1080P/720P/960H/D1/CIF(1fps–25/30fps); Sub stream: 960H@(1fps–15fps); D1/CIF@(1 fps–25/30fps) |
| Onvif | 21.06 |
| Record Mode | General, motion detection; intelligent; alarm; POS |
| Audio Input | 1-channel RCA (external) 16-channel BNC (coaxial audio) |
| Audio Output | 1, RCA |
| Audio Compression | G.711A; G.711u; PCM |
| Alarm Input | Motion detection, video loss, tampering |
| Alarm Output | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, pre-set, email |
| Network Interface | Chrome, IE9 or above, Firefox |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| Power | 12 VDC, 5 A |
| Dimensions | 1U, 375.0 × 289.4 × 53.0mm (W × D × H) |
