Dahua Mains Powered Wireless Gateway for interconnected fire alarm systems.
Dahua Mains Powered Wireless Gateway for interconnected fire alarm systems. Supports up to 128 WisuLink wireless devices via 868 MHz radio, with multi...
Dahua Mains Powered Wireless Gateway for interconnected fire alarm systems. Supports up to 128 WisuLink wireless devices via 868 MHz radio, with multiplex connectivity over Ethernet, Wi-Fi (2.4 GHz), and 4G LTE. Includes rechargeable lithium battery backup, OTA upgrade support, and remote monitoring via the Wisualarm app.
Contact 0345 863 9750 for availability
SKU:
DHI-HY-GW02A
Click to copy
✔ Copied!
Product Details
Dahua Mains Powered Wireless Gateway for interconnected fire alarm systems. Supports up to 128 WisuLink wireless devices via 868 MHz radio, with multiplex connectivity over Ethernet, Wi-Fi (2.4 GHz), and 4G LTE. Includes rechargeable lithium battery backup, OTA upgrade support, and remote monitoring via the Wisualarm app.
| Manufacturer | Dahua |
|---|---|
| Alarm Mode | Visual and audible |
| Alarm Volume | 70 dB at 3 m |
| App | Wisualarm (Android and iOS) |
| Battery Backup | 4750 mAh, 17.57 Wh rechargeable lithium |
| Certifications | CE, UKCA, PSTI, RCM |
| Connectivity | Ethernet, Wi-Fi, 4G LTE |
| Dimensions Mm | 175 x 175 x 36 |
| Installation | Free-standing or wall mounting |
| LED Indicator | Single multi-colour LED (Green/Red/Yellow/Blue) indicating standby, pairing, alarm, fault, network and reset states |
| LTE Fdd Bands | B1, B3, B5, B7, B8, B20, B28 |
| Max Connected Devices | 128 |
| Operating Frequency | 868 MHz (DHI-HY-GW02A) / 925 MHz (DHI-HY-GW02A-R9) |
| Ota Upgrade | true |
| Power Supply | AC 100–240V |
| SD Card Slot | true |
| SIM Card Slots | Dual SIM (main + standby), single standby |
| Tamper Protection | Tamper switch and back cover tamper alarm |
| Weight G | 500 |
| WIFI Frequency | 2.4 GHz (IEEE 802.11b/g/n) — incompatible with 5 GHz |
| WIFI Transmission Range | 50 m (164 ft) |
| Casing Material | ABS |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | ≤95% RH (non-condensing) |
