Dahua 2-Wire Hybrid Villa Door Station with Auto IR Illumination and Half-Duplex Video Intercom.
Dahua 2-Wire Hybrid Villa Door Station with Auto IR Illumination and Half-Duplex Video Intercom. Features a 1/2.8" 2MP CMOS HDR camera with 110° horiz...
Dahua 2-Wire Hybrid Villa Door Station with Auto IR Illumination and Half-Duplex Video Intercom. Features a 1/2.8" 2MP CMOS HDR camera with 110° horizontal field of view, DWDR, and 3D noise reduction. Aluminum alloy front panel with IP65/IK07 protection, anti-tamper alarm, and support for local lock and secondary lock control via RS-485.
Contact 0345 863 9750 for availability
SKU:
DHI-VTO2003F
Click to copy
✔ Copied!
Product Details
Dahua 2-Wire Hybrid Villa Door Station with Auto IR Illumination and Half-Duplex Video Intercom. Features a 1/2.8" 2MP CMOS HDR camera with 110° horizontal field of view, DWDR, and 3D noise reduction. Aluminum alloy front panel with IP65/IK07 protection, anti-tamper alarm, and support for local lock and secondary lock control via RS-485.
| Manufacturer | Dahua |
|---|---|
| Ingress Protection | IP65 |
| Image Sensor | 1/2.8" 2MP CMOS HDR |
| Lighting Type | Auto IR |
| Alarm Output | 1 |
| Audio Input | 1 |
| Audio Mode | Two-way half-duplex |
| Audio Output | Built-in speaker |
| Button Type | Mechanical |
| Resolution | 2MP |
| Casing Material | Aluminum Alloy |
| Certifications | CE, FCC |
| Compatible Accessories | VTM115 (Surface Box), VTM114 (Flush Box), VTM05R (Surface Box with Rain Cover), VTNC1003C (2-wire Controller) |
| Day Night | Auto (ICR) / Color / B&W |
| Dimensions Mm | 130 x 96 x 28.5 |
| Door Status Detection | 1 |
| Exit Button | 1 |
| Field Of View Horizontal | 110° |
| Field Of View Vertical | 60° |
| Frame Rate NTSC | 30fps |
| Frame Rate PAL | 25fps |
| Gross Weight Kg | 0.502 |
| IK Rating | IK07 |
| Installation | Flush Mount / Surface Mount |
| Lock Control | 1 |
| Noise Reduction | 3D NR |
| Operating Altitude | 0–3000m |
| Operating Humidity | 10%–90% RH non-condensing |
| Operating Temperature | -40°C to +60°C |
| Power Adapter | Optional |
| Power Consumption Standby | ≤1.5W |
| Power Consumption Working | ≤10W |
| Power Output | 12V / 200mA |
| Power Supply | 2-wire controller (48VDC via controller) |
| RS485 Ports | 1 |
| Storage Humidity | 95% RH non-condensing |
| Storage Temperature | -40°C to +70°C |
| Tamper Alarm | true |
| Unlock Mode | Remote unlock |
| Video Message | Yes (SD card in VTH required) |
| Video Resolution NTSC | 960 x 480 |
| Video Resolution PAL | 960 x 576 |
| WDR | DWDR |
