Dahua Video Intercom Fingerprint Reader Module for VTO4103FB Series modular door station.
Dahua Video Intercom Fingerprint Reader Module for VTO4103FB Series modular door station. Features an embedded processor with aluminum alloy casing, r...
Dahua Video Intercom Fingerprint Reader Module for VTO4103FB Series modular door station. Features an embedded processor with aluminum alloy casing, rated IP65 weatherproof and IK07 vandal-resistant. Supports flush and surface mount installation, operates from -30°C to +60°C, and provides 5VDC output to power other modules in the system.
Contact 0345 863 9750 for availability
SKU:
DHI-VTO4103FB-MF-Black
Click to copy
✔ Copied!
Product Details
Dahua Video Intercom Fingerprint Reader Module for VTO4103FB Series modular door station. Features an embedded processor with aluminum alloy casing, rated IP65 weatherproof and IK07 vandal-resistant. Supports flush and surface mount installation, operates from -30°C to +60°C, and provides 5VDC output to power other modules in the system.
| Manufacturer | Dahua |
|---|---|
| Ingress Protection | IP65 (silicone sealant required for installation) |
| Appearance Color | Black |
| Casing Material | Aluminum alloy |
| Compatible Series | VTO4103FB Modular Door Station Series |
| Dimensions | 100 mm × 100 mm × 38.50 mm (3.94" × 3.94" × 1.52") |
| Gross Weight | 0.33 kg (0.73 lb) |
| IK Rating | IK07 |
| Installation | Flush Mount; Surface Mount |
| Main Processor | Embedded Processor |
| Module Type | Fingerprint Reader Module |
| Operating Humidity | 10%–90% RH |
| Operating Temperature | -30°C to +60°C (-22°F to +140°F) |
| Power Consumption | ≤0.5 W |
| Power Output | 5 VDC (provides power for other modules) |
| Power Supply | 5 VDC (provided by other modules) |
