Dahua Modular Door Station Button Module with 4 Mechanical Buttons.
Dahua Modular Door Station Button Module with 4 Mechanical Buttons. Designed for use within the VTO4202F modular video intercom system, this module pr...
Dahua Modular Door Station Button Module with 4 Mechanical Buttons. Designed for use within the VTO4202F modular video intercom system, this module provides 4 mechanical call buttons in a compact 100mm x 50mm aluminium alloy housing. Supports flush and surface mount installation with IP65 weather resistance and IK07 impact protection.
Contact 0345 863 9750 for availability
SKU:
DHI-VTO4202F-MDB4
Click to copy
✔ Copied!
Product Details
Dahua Modular Door Station Button Module with 4 Mechanical Buttons. Designed for use within the VTO4202F modular video intercom system, this module provides 4 mechanical call buttons in a compact 100mm x 50mm aluminium alloy housing. Supports flush and surface mount installation with IP65 weather resistance and IK07 impact protection.
| Manufacturer | Dahua |
|---|---|
| Ingress Protection | IP65 |
| Appearance Color | Silver |
| Button Type | Mechanical |
| Casing Material | Aluminum alloy |
| Certifications | CE EMC; CE LVD |
| Dimensions | 100.0 mm × 50.0 mm × 26 mm (3.94" × 1.97" × 1.02") |
| Gross Weight | 0.24 kg (0.53 lb) |
| IK Rating | IK07 |
| Installation Note | Silicone sealant required for IP65 installation |
| Installation Type | Flush Mount; Surface Mount |
| Number Of Buttons | 4 |
| Operating Altitude | 0 m–3,000 m (0 ft–9,842.52 ft) |
| Operating Environment | Outdoor |
| Operating Humidity | 10%–90% (RH), non-condensing |
| Operating Temperature | -30 °C to +60 °C (-22 °F to +140 °F) |
| Power Consumption | ≤0.2 W (standby), ≤0.6 W (working) |
| Power Output | 5 VDC (provides power to other modules) |
| Power Supply | 5 VDC (provided by other modules) |
| Series | VTO420XF-X Modular Door Station Series |
| Storage Humidity | 30%–75% (RH) |
| Storage Temperature | 0 °C to +40 °C (+32 °F to +104 °F) |
