Dahua IC Card Reader Module for modular video intercom door stations.
Dahua IC Card Reader Module for modular video intercom door stations. Supports contactless IC card authentication at 13.56 MHz with a card reading dis...
Dahua IC Card Reader Module for modular video intercom door stations. Supports contactless IC card authentication at 13.56 MHz with a card reading distance of 1–3 cm. Housed in an aluminium alloy casing with IK07 impact resistance and IP65 weatherproofing (silicone sealant required). Powered by 5 VDC supplied from connected modules and draws up to 2 W.
Contact 0345 863 9750 for availability
SKU:
DHI-VTO4202FB-MR-Black
Click to copy
✔ Copied!
Product Details
Dahua IC Card Reader Module for modular video intercom door stations. Supports contactless IC card authentication at 13.56 MHz with a card reading distance of 1–3 cm. Housed in an aluminium alloy casing with IK07 impact resistance and IP65 weatherproofing (silicone sealant required). Powered by 5 VDC supplied from connected modules and draws up to 2 W.
| Manufacturer | Dahua |
|---|---|
| Ingress Protection | IP65 (silicone sealant required for installation) |
| Card Reading Distance | 1 cm – 3 cm (0.39" – 1.18") |
| Card Type | IC card (13.56 MHz) |
| Casing Material | Aluminium alloy |
| Dimensions | 100 mm × 50.0 mm × 28.50 mm (3.94" × 1.97" × 1.12") |
| Gross Weight | 0.16 kg (0.35 lb) |
| IK Rating | IK07 |
| Installation | Flush Mount / Surface Mount |
| Max Transmission Power | 42 dBuA/m @ 10 m |
| Operating Humidity | 10%–90% RH |
| Operating Temperature | -30 °C to +60 °C (-22 °F to +140 °F) |
| Power Consumption | ≤2 W |
| Power Output | 5 VDC (provides power for other modules) |
| Power Supply | 5 VDC (provided by other modules) |
| Processor | Embedded Processor |
| RFID Frequency | 13.56 MHz |
| RFID Modulation | AM |
