Dahua 12V 200Ah Valve-Regulated Gel Lead Acid Battery.
Dahua 12V 200Ah Valve-Regulated Gel Lead Acid Battery. Designed for deep-cycle applications including solar and wind power systems, UPS/EPS, and remot...
Dahua 12V 200Ah Valve-Regulated Gel Lead Acid Battery. Designed for deep-cycle applications including solar and wind power systems, UPS/EPS, and remote security equipment installations. Offers 30% higher cycle life than conventional batteries using SiO2 and H2SO4 compound gelled electrolyte, with a 12-year float charge design life and maintenance-free operation.
Contact 0345 863 9750 for availability
SKU:
PFM372-200-CNF
Click to copy
✔ Copied!
Product Details
Dahua 12V 200Ah Valve-Regulated Gel Lead Acid Battery. Designed for deep-cycle applications including solar and wind power systems, UPS/EPS, and remote security equipment installations. Offers 30% higher cycle life than conventional batteries using SiO2 and H2SO4 compound gelled electrolyte, with a 12-year float charge design life and maintenance-free operation.
| Manufacturer | Dahua |
|---|---|
| Applications | Solar/wind power systems, UPS/EPS, remote security equipment, telecommunication base stations, mobile medical equipment, recreational vehicles |
| Battery Type | Valve-Regulated Gel Lead Acid (VRLA) |
| Capacity 10HR | 200Ah |
| Capacity 20HR | 212Ah |
| Capacity 3HR | 154.8Ah |
| Capacity 5HR | 174.5Ah |
| Certifications | CE (EN61000-6-1, EN61000-6-3, EN60896-21, EN60896-22), IEC60896-21, IEC60896-22, UL MH28539 |
| Charging Temperature | 0°C to +50°C |
| Connection | Lead-out wire (6mm², 1.0m each) |
| Cycle Voltage | 14.6V–14.8V DC |
| Design Life | 12 years (float charging) |
| Discharging Temperature | -20°C to +60°C |
| Electrolyte | SiO2 and H2SO4 compound gelled electrolyte |
| Float Voltage | 13.6V–13.8V DC |
| Internal Resistance | 4.5mΩ (fully charged at 25°C) |
| Max Charging Current | 40A (0.2C) |
| Max Discharging Current | 2000A (5 seconds) |
| Rated Voltage | 12V DC |
| Recommended Storage Temperature | 0°C to +40°C |
| Self Discharge | ≤3% per month at 25°C |
| Casing Material | ABS (UL94-HB flame retardant) |
| Dimensions | 522mm × 240mm × 219mm (L × W × H) |
| Net Weight | 58.0 kg |
| Gross Weight | 58.4 kg |
| Operating Humidity | <95% RH |
