Dahua 275W Monocrystalline Silicon Solar Module.
£323.00
In stock
SKU
DH-PFM371-M275
Dahua 275W Monocrystalline Silicon Solar Module. Delivers up to 275W peak power with a 19.29% panel conversion efficiency and silicon chip light conversion rate of 22% or above. Compatible with MC4 connectors, rated for operating temperatures from -40°C to +85°C, and built to last up to 25 years with IK07 impact protection.
Dahua 275W Monocrystalline Silicon Solar Module. Delivers up to 275W peak power with a 19.29% panel conversion efficiency and silicon chip light conversion rate of 22% or above. Compatible with MC4 connectors, rated for operating temperatures from -40°C to +85°C, and built to last up to 25 years with IK07 impact protection.
| Manufacturer | Dahua |
|---|---|
| Applicable Area | Locations with solar radiation exposure >3.5 hours per day |
| Certifications | CE (EN 61000-6-1, EN 61000-6-3), UKCA (EN 61000-6-1, EN 61000-6-3), FCC (47 CFR Part 15, Subpart B) |
| Current Temperature Coefficient | +0.07%/K |
| Dielectric Strength | 1000V |
| Lifespan | Up to 25 years |
| Main Body Material | Silicon; tempered glass; aluminium frame |
| Max Mechanical Load Front | 5400 Pa |
| Max Mechanical Load Rear | 2400 Pa |
| Max Power | 275W (Power Tolerance: ±3%) |
| Open Circuit Voltage | 39.63V |
| Operating Altitude | <3000m |
| Operating Current | 8.42A |
| Operating Voltage | 32.66V |
| Output Port | Compatible MC4 connector |
| Packaging Method | 2 pieces per carton |
| Panel Conversion Efficiency | 19.29% |
| Panel Type | Monocrystalline silicon |
| Power Temperature Coefficient | -0.38%/K |
| Protection Rating | IK07 |
| Short Circuit Current | 8.9A |
| Silicon Chip Array | 4 × 15 |
| Silicon Chip Conversion Efficiency | ≥22% |
| Silicon Chip Size | 105mm × 210mm |
| Voltage Temperature Coefficient | -0.36%/K |
| Dimensions | 1620mm × 880mm × 35mm (L × W × H) |
| Net Weight | 14kg |
| Gross Weight | 49.5kg |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | 0°C to +40°C |
| Operating Humidity | <95% RH |
| Storage Humidity | <95% RH |
