Dahua 5MP AI-Fire Smoke Sensing Network Camera with Temperature and Humidity Detection.
Dahua 5MP AI-Fire Smoke Sensing Network Camera with Temperature and Humidity Detection. Integrates photoelectric smoke detection, AI flame detection, ...
Dahua 5MP AI-Fire Smoke Sensing Network Camera with Temperature and Humidity Detection. Integrates photoelectric smoke detection, AI flame detection, and heat/humidity monitoring with a 5MP 1/2.7" CMOS camera featuring a 2.0mm fixed lens and IR illumination up to 20m. Supports H.265 compression, PoE power, built-in 85dB buzzer, and up to 256GB Micro SD card storage.
Contact 0345 863 9750 for availability
SKU:
DHI-HY-SAV849HAP-ET
Click to copy
✔ Copied!
Product Details
Dahua 5MP AI-Fire Smoke Sensing Network Camera with Temperature and Humidity Detection. Integrates photoelectric smoke detection, AI flame detection, and heat/humidity monitoring with a 5MP 1/2.7" CMOS camera featuring a 2.0mm fixed lens and IR illumination up to 20m. Supports H.265 compression, PoE power, built-in 85dB buzzer, and up to 256GB Micro SD card storage.
| Manufacturer | Dahua |
|---|---|
| Resolution | 5MP |
| Camera Power Supply | 12V DC / PoE (802.3af) |
| IR Length | 20m |
| Lens Size | 2.0mm |
| Alarm In | 2 channels (5mA, 3V–5V DC) |
| Alarm Out | 2 channels (300mA, 12V DC) |
| Alarm Types | Smoke alarm, fault alarm, low battery alarm, heat alarm, humidity alarm |
| Alarm Volume | ≥85 dB(A) @ 3m |
| Audio In | 1 channel (RCA) |
| Audio Out | 1 channel (RCA) |
| Basic Power Consumption | 2.1W (12V DC) / 2W (PoE) |
| Battery | 3V lithium battery (backup) |
| Battery Life | >3 years |
| Built In Mic | true |
| Built In Speaker | true |
| Certification | CE-CRP: EN 14604:2005/AC:2008, CE-LVD: EN 62368-1, CE-EMC: 2014/30/EU, FCC Part 15 Subpart B |
| Close Focus Distance | 0.2m |
| Compression | H.265 / H.264 / H.264H / H.264B |
| Field Of View | Horizontal 144°, Vertical 92°, Diagonal 179.6° |
| Image Sensor | 1/2.7" CMOS |
| Installation | Ceiling mount |
| Interoperability | ONVIF, MileStone, Genetec, CGI, PISA |
| IR Leds | 2 |
| Lens Mount | M8 |
| Lens Type | Fixed-focal |
| Max Aperture | F2.0 |
| Max Power Consumption | 4.9W (12V DC) / 4.8W (PoE) |
| Max Resolution | 2592 x 1944 |
| Max Users | 20 |
| Min Illumination Colour | 0.002 Lux |
| Min Illumination Dark | 0.0002 Lux |
| Min Illumination IR | 0 Lux |
| Network Port | 1x RJ-45 PoE 10/100M |
| Noise Reduction | 3D NR |
| Operating Current Camera Excluded | ≤30uA |
| Operating Current Camera Included | ≤300mA |
| Privacy Masking | 8 areas |
| Protection Area | 30m² – 60m² |
| RS485 | 1 port (1200–115200 bps) |
| Smart Codec | Smart H.265+ / Smart H.264+ |
| Smart Features | AI flame detection, smoke detection, heat detection, humidity detection, motion detection, audio detection, video tampering, scene change detection |
| SNR | >56dB |
| Standard | PAL (DHI-HY-SAV849HAP-ET) |
| Storage | Micro SD up to 256GB, FTP, SFTP, NAS |
| WDR | 90dB |
| Working Principle | Photoelectric |
| Camera Body Style | Ceiling mount (smoke detector style, circular) |
| Casing Material | Plastic |
| Dimensions | 175.3 x 120.0 x 81.6mm |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 0%–95% RH (non-condensing) |
